Office & Gym Garden Room with Canopy in Binley Woods, Coventry – 8500mm x 3500mm

Canopy Design Garden Room in Coventry

In this case study, we showcase our exceptional Garden Room with Canopy design, located in Binley Woods, Coventry, UK.

This project focused on designing and building a sleek, functional garden building with a canopy, tailored to the client’s needs in Binley Woods, Coventry. Our team was excited to take on this project, which came to us through word-of-mouth—a reflection of our dedication to quality craftsmanship and client satisfaction.

The process began with a detailed consultation to understand the purpose of the space, ensuring the design aligned with both functionality and aesthetics. From there, we developed a layout that maximised usability while fitting seamlessly into the surrounding environment. Every material and finish were carefully selected to create a structure that is both durable and visually stunning.

Key Features:

  • Bespoke Design and Versatility: A custom-built garden building with an attached canopy, designed for multi-functional use while complementing the outdoor space.
  • Premium Materials and Finishes: Featuring Red Western Cedar cladding with shadow-line detailing, insulated micro rib panels in Anthracite, and a durable Osmo UV oil finish.
  • Thermal Efficiency and Robust Construction: Built with a 1.6mm light-gauge steel frame, insulated wall cavities, and a reinforced concrete foundation for year-round comfort and stability.
  • Elegant Doors and Windows: Installed bifold and composite doors, along with top-hung and fixed windows, all finished in Anthracite powder coating for a modern look.
  • High-Quality Interior Details: Plastered and painted walls, durable OSB board, integrated chrome electrical fixtures, fire-rated lighting, and a certified consumer unit for safe, reliable use.

Build Specifications

FOUNDATION

This project was built on a durable concrete pad foundation, ensuring a stable and long-lasting base. This type of foundation provides excellent support, prevents shifting over time, and is ideal for creating a level surface for the structure.

  • Concrete Pad

STRUCTURE

Using a durable 100mm depth, 1.6mm light gauge steel frame, ensured strength and stability. The insulated cavity within the frame provides excellent thermal efficiency, making the space comfortable year-round while maintaining a sleek, modern design.

  • 100mm depth 1.6mm Light gauge steel frame (insulated cavity)

CLADDING - FRONTAL

The quartz grey vertical composite cladding adds a sleek, modern finish to the garden room while being highly durable and low maintenance. Designed to withstand the elements, this cladding solution ensures the structure stays looking great year-round without the need for upkeep.

  • Quartz grey coloured vertical composite cladding solution (0 maintenance)

CLADDING - SIDEWALL/BACKWALL

The sidewall and backwall of this room are constructed using 100mm insulated micro rib panels in a sleek anthracite finish. This material not only provides a modern, stylish look but also ensures excellent thermal insulation, making the space comfortable year-round.

  • 100mm Insulated micro rib panel (Anthracite)

ROOF

The roof is constructed using a 40mm insulated box profile panel in a sleek Anthracite finish. This high-quality material not only provides excellent thermal insulation to maintain a comfortable environment year-round but also adds a modern, stylish touch to the garden room’s design.

  • 40mm Insulated box profile panel (Anthracite)

DOORS

We installed two sets of 3000mm x 2050mm bifold doors, crafted from durable powder-coated aluminium in a sleek Anthracite (RAL 7016) finish. These doors not only provide a modern aesthetic but also create a seamless connection between the indoor and outdoor spaces.

  • 2x – 3000mm x 2050mm bifold doors powder coated aluminium (RAL 7016 – Anthracite)

WINDOWS

We installed durable, powder-coated aluminium windows in sleek RAL 7016 Anthracite for a stylish, long-lasting finish. The 800mm x 400mm top-hung window offers ventilation in a compact design, ideal for smaller spaces, while the larger 1000mm x 2000mm window brings in plenty of natural light.

  • 800mm x 400mm top hung opening window powder coated aluminium (RAL 7016 – Anthracite)
  • 1000mm x 2000mm half opening top hung window powder coated aluminium (RAL 7016 – Anthracite)

INTERNAL WALLS

The internal walls of this garden building are fully boarded and finished with a smooth plaster skim for a polished look. Perfect for use as a gym or office, the walls feature a durable, high-quality spray-painted finish that enhances the modern design.

  • Full Boarded and a professionally plastered skim finish (gym/office) finished with a spray-painted finish

INTERNAL ELECTRIC FIXTURES

To make this garden building functional and stylish, we added brushed chrome fixtures, 10 double plug sockets, 2 USB sockets, and 12 fire-rated downlights for safety. Ethernet ports ensure easy connectivity, while sleek switches offer simple control. A certified consumer unit ensures safe, reliable power, perfect for work, relaxation, or entertainment.

  • 10 x Brushed chrome double plug sockets
  • 2 x Brushed chrome USB double plug sockets
  • 12 x Brushed chrome fire rated down lights
  • 2 x Brushed chrome Ethernet ports
  • 2 x Brushed chrome double switches
  • 1 x Fully tested and certified consumer unit

HEATING

For added comfort, this garden room features two sleek glass panel wall-mounted heaters. These modern heaters provide efficient warmth, ensuring the space stays cosy year-round, whether you’re working, relaxing, or entertaining.

  • 2 x Glass panel wall mounted heater

EXTERNAL LIGHTING FIXTURES

To enhance the garden building’s functionality and aesthetic appeal, we installed 6 brushed steel fire-rated downlights within the canopy. These modern, durable fixtures not only provide ample illumination for evening use but also add a sleek, contemporary touch to the overall design.

  • 6 x Brushed steel fire rated down lights within canopy

FLOORING

We installed high-quality 12mm laminate flooring, designed to combine style with durability. The Oak Grey option adds a natural, timeless look, while the Dark Grey Slate effect provides a more modern, textured finish. Both options feature an absorption underlay to enhance comfort, reduce noise, and provide excellent insulation.

  • 12mm Oak grey laminate floor with absorption underlay
  • 12mm Dark Grey slate effect laminate with absorption underlay

CANOPY

The canopy features a fully powder-coated aluminium soffit and fascia system, finished in RAL 7016 Anthracite for a sleek, modern look. This durable design not only enhances the garden room’s aesthetic but also provides long-lasting protection against the elements.

  • Full powder coated aluminium soffit and facia system (RAL 7016 – Anthracite)

With thoughtfully chosen features and high-quality materials, our garden buildings in Coventry provide a stylish, durable, and versatile outdoor space designed to complement your lifestyle.

For more details about our garden rooms with canopies in Coventry or to receive a tailored quote for your project, get in touch with us today.
